CleanMax CM-WAV Motor Assembly Parts replacement parts for Model CM-WAV. Can’t find your part? Call us at 763-535-0770.
Click on any part in the diagram below or in the table to go directly to that part’s product page.
Genuine CleanMax CM-WAV suction motor assembly parts — the vacuum motor, motor mounting screws, gasket, and the wiring harness components that make up the sealed suction system on the wide-area vacuum. Twin City Vacuum has sold and serviced CleanMax equipment since 1956, sourcing every part directly from Tacony. Call 763-535-0770 or visit 5415 West Broadway, Crystal, MN 55428.
| # | Image | Part Description | Part Number | Link |
|---|---|---|---|---|
| 01 |  | Vac Motor Wav – 30092 | 30092 | View Part |
| 02 | Gasket – 30090 | 30090 | View Part | |
| 04 | Worm Gear Clamp 6in – 33107 | 33107 | View Part | |
| — | Motor Mounting Screw #10-16 x 3/4 30620 | 30620 | View Part |
Frequently Asked Questions
What motor assembly parts fit the CleanMax CM-WAV wide area vacuum?
The CM-WAV motor assembly includes the vacuum (suction) motor (30092), its mounting screws (30620), the motor gasket (30090), and the wiring harness and ground terminals. Match each item number on the diagram above to the table below to order the right part.
How do I know if my CM-WAV suction motor needs replacing?
Loss of suction that a clear airway and fresh filters do not fix, a burning smell, loud bearing noise, or a motor that will not start all point to the suction motor. Confirm the airway and filters first, then replace the motor from the table above if needed.
Does the CM-WAV motor come with a gasket and mounting hardware?
The suction motor (30092), motor gasket (30090), and mounting screws (30620) are listed as separate items so you can order exactly what you need. Replacing the gasket whenever the motor is out keeps the airway sealed.
How do I order CleanMax CM-WAV motor parts or get help?
Add any part directly to your cart from the table on this page, or call 763-535-0770. Our staff at 5415 West Broadway, Crystal, MN 55428 has serviced CleanMax equipment since 1956 and can confirm the right motor part for your CM-WAV.
Looking for other CleanMax CM-WAV parts? Browse the complete CleanMax CM-WAV parts diagrams, or call 763-535-0770. Learn more at CleanMax.
