& ZM-400 Motor Assembly Straight Shaft D113-1500

The Motor Assembly Straight Shaft (part# D113-1500) is the complete genuine Tacony OEM motor unit for the CleanMax ZM-200 and ZM-400 commercial upright vacuums. arrives as a ready-to-install straight-shaft motor — the same direct-air motor design these Zoom-series uprights use to generate suction and to drive the brushroll belt from the motor pulley.

On the ZM-200 and ZM-400, the straight-shaft motor spins the flat drive belt (part# B014-0814B) that turns the wood agitator, while the motor fan pulls debris up through the nozzle and into the bag. Because it is a straight-shaft unit, it is not interchangeable with the pulley-shaft motor (D113-1400) used on the ZM-600 — ordering the correct shaft type is essential, which is why we list them as separate parts.

Replacing the entire motor assembly is the right call when the motor has burned out, is drawing excessive current and tripping the circuit breaker, runs loudly with worn bearings, or no longer spins with strong suction. Installing a complete assembly restores full performance in one step rather than rebuilding individual internal components.

This is a genuine Tacony part built to the original factory specification, so it seats correctly in the ZM housing and mates to the existing fan washers, fan nut, and belt without modification.

Compatible Models for the Motor Assembly Straight Shaft

• CleanMax ZM-200 — Zoom 200 Commercial Upright
• CleanMax ZM-400 — Zoom 400 Commercial Upright

Twin City Vacuum has been selling and servicing CleanMax equipment since 1956. All parts are sourced directly from Tacony. Browse the full CleanMax ZM-200 nozzle assembly parts list, or see the range at CleanMax.com.

Frequently Asked Questions

What does the Motor Assembly Straight Shaft (part# D113-1500) do?

The Motor Assembly Straight Shaft (part# D113-1500) is the direct-air motor that creates the vacuum suction on the CleanMax ZM-200 and ZM-400 and drives the brushroll belt from its straight output shaft.

How do I know if my Motor Assembly Straight Shaft (part# D113-1500) needs replacing?

Replace the D113-1500 motor assembly if the vacuum has lost suction, the motor will not start, it runs unusually loud or hot, smells of burning, or repeatedly trips the machine’s circuit breaker. Worn motor bearings and a failed armature are common causes.

What models is the Motor Assembly Straight Shaft (part# D113-1500) compatible with?

The Motor Assembly Straight Shaft (part# D113-1500) fits the CleanMax ZM-200 and CleanMax ZM-400 straight-shaft uprights. The ZM-600 uses the pulley-shaft motor D113-1400 instead — the two are not interchangeable.

How do I order the Motor Assembly Straight Shaft (part# D113-1500) or get help?

You can add the Motor Assembly Straight Shaft (part# D113-1500) directly to your cart on this page, or call us at 763-535-0770. Our staff at 5415 West Broadway, Crystal, MN 55428 has been servicing CleanMax equipment since 1956 and can help confirm the right part for your machine.
