Lindhaus RX Hepa Head Parts

Find genuine Lindhaus RX Hepa (head) replacement parts. Can’t find your part? Call us at 763-535-0770 or visit us at 5415 West Broadway, Crystal, MN 55428.

Click any numbered dot on the schematic below to open that part, or find it by its callout number in the parts table underneath.

The parts table below covers the head of the Lindhaus RX Hepa upright vacuum, numbered to match the schematic diagram above. Each row links to that part with its Lindhaus part number and current price. A few parts on the diagram are not yet stocked online — call 763-535-0770 to order those.

#	Image	Part Description	Part Number	Price
1		Lindhaus Rx Hepa Base Housing 15", 18" Or 20"	—	$92.00
2		Lindhaus Rx Hepa Base Housing Cover 380 (15”)	—	$56.00
3		Lindhaus Rx Hepa Joint Complete 120v	083210380	$93.80
4		Lindhaus Rx Hepa Joint Pin Slide	002290305	$2.80
5		Lindhaus Rx Hepa Support Right Joint	081910080	$17.00
6		Lindhaus Rx Hepa Plunger	001940036	$2.60
7		Lindhaus Rx Hepa Spring, Detente	010390009	$1.20
8		Lindhaus Rx Hepa Double Pin Washer	001930036	$2.40
9		Lindhaus Rx Hepa Double Release Plate	002180105	$2.00
10		Lindhaus Rx Hepa Foot Pedal	002550105	$12.86
11		Lindhaus Rx Hepa Support Left Joint	081920080	$17.00
12		Lindhaus Rx Hepa Switch Activator Pin	000670036	$1.00
13		Lindhaus Rx Hepa Spring Switch Activator Pin	010480009	$1.00
14		Lindhaus Rx Hepa Microswitch	020640000	$16.60
15		Lindhaus Rx Hepa Brush Height Adjuster	000990305	$7.40
16		Lindhaus Rx Hepa Adjusting Knob	003130104	$10.40
17		Lindhaus Rx Hepa Front Axle	011330029	$26.40
18		Lindhaus Rx Hepa Front Wheel Rubber	02260000	$5.60
19		Lindhaus Rx Hepa Spring Brush Adjust	011160009	$2.40
20		Lindhaus Rx Hepa Rear Axle	011390009	$15.00
21		Lindhaus Rx Hepa Rear Wheel Rubber	02270000	$7.76
22		Lindhaus Rx Hepa Wheel Retainer Cap	012840009	$1.06
23		Lindhaus Rx Hepa Screw 2.9 X 16 Pack Of 20	085610009	$8.60
24		Lindhaus Rx Hepa Filter Grill	002140104	$16.00
25		Lindhaus Rx Hepa Exhaust Filter	0011240316	$45.20
26		Lindhaus Rx Hepa Stop Grill Plate	002160104	$0.80
27		Lindhaus Rx Hepa Brush Motor 380 (15")	—	$148.00
28		Lindhaus Rx Hepa Motor Gasket Kit	082050381	$7.76
29		Lindhaus Rx Hepa Metal Spacer	002890029	$2.40
30		Lindhaus Rx Hepa Metal Pulley	002880029	$4.99
31		Lindhaus Rx Hepa Nut, Pinion	—	$8.72
32		Lindhaus Rx Hepa Circuit Board	020370000	$70.00
33		Lindhaus Rx Hepa Channel Cover	002170104	$16.20
34		Lindhaus Rx Hepa Transmission Support W/ Pulley	082600081	$66.80
35		Lindhaus Rx Hepa Brush Pulley W/ Metal Insert	086160381	$9.40
37		Lindhaus Rx Hepa Timing Belt 7mm	010790300	$16.00
38		Lindhaus Rx Hepa Wheel Support	081940081	$19.80
39		Lindhaus Rx Hepa Screw 3.9 X 16 Pack Of 20	085560009	$7.60
40		Lindhaus Rx Hepa Roller Support	081950081	$28.80
41		Lindhaus Rx Hepa Side Lever	002210304	$12.80
42		Lindhaus Rx Hepa Front Bumper 380 (15”)	—	$14.80
43		Lindhaus Rx Hepa Back Bumper 380 (15”)	—	$2.40
44		Lindhaus Rx Hepa Screw 4.8 X 50 Pack Of 20	087270009	$25.20
45		Lindhaus Rx Hepa Screw 3.5 X 38 Pack Of 20	087280009	$12.40
46		Lindhaus Rx Hepa Side Cover	002150104	$11.60
47		Lindhaus RX Hepa BRUSH ROLLER	—	$58.00
48		Lindhaus Rx Hepa Filter Brush Motor	010580016	$8.40
49		Lindhaus Rx Hepa Screw 3.9 X 13 Pack Of 20	085590009	$9.60
50		Lindhaus Rx Hepa Screw 3.5 X 16	010030009	$0.24
51		Lindhaus Rx Hepa Screw 2.2 X 16 Pack Of 20	086950009	$7.60
52		Lindhaus Rx Hepa Lens Set Red & Green – 82940081	082940081	$8.60
53		Lindhaus Rx Hepa Throat Cover Felt Strip Only	011000017	$0.68
54		Lindhaus Rx Hepa Base Metal Guides Set	—	$24.00
55		Lindhaus Rx Hepa O-ring	012480307	$0.70
56		Lindhaus Rx Hepa Male Elec Connection Set, 3 Prong – 82490080	082490080	$23.00

Lindhaus RX Hepa Head Parts — Frequently Asked Questions

How do I find the right part on the Lindhaus RX Hepa Head schematic?

Every numbered dot on the diagram matches a numbered row in the table above. Click the dot or the row to open that exact part with its Lindhaus part number and price. Not sure which number? Call 763-535-0770 with your model.

What are the most common Lindhaus RX Hepa Head parts?

Brushrolls, belts, HEPA and exhaust filters, bags, base plates, roller covers, bumpers and switches are the most frequently replaced parts — all listed above by schematic number.

Do Lindhaus RX Hepa parts fit other Lindhaus RX models?

Many RX Hepa and RX Eco-Force (RX380/RX450/RX500) parts cross over, but some are size- or generation-specific. Confirm by part number before ordering, or call us.

How do I order a Lindhaus RX Hepa part or get help?

Add any part directly to your cart from its product page, or call 763-535-0770. Our staff at 5415 West Broadway, Crystal, MN 55428 has serviced Lindhaus vacuums since 1956 and can confirm the right part for your Lindhaus RX Hepa.

Browse the RX Hepa body parts, all Lindhaus vacuum parts, or the RX parts hub.
