Tornado 98220 main assembly parts for the PS Series professional spotter, Model 98220. Can’t find your part? Call us at 763-535-0770.
Click on any numbered part in the diagram below to go directly to that part’s product page.
1. Tornado Screw #8-32 x 3/4" – 006002. Tornado Lock Washer #10 Heavy Series – 017133. Tornado Keps Nut – 029564. Tornado Screw #8-32 x 3/8 in. – 029955. Tornado Sealing Washer 1/4 in. – 077416. KEPS Nut – 108926. KEPS Nut – 108927. Tornado Washer 1/2″ I.D. Zinc Plated – 129578. QD Coupler 1/4”M x 1/4” FPT – PX59. Tornado Two-Ear Hose Clamp – PX5210. Tornado Brass Elbow Fitting 45 Degree – 1507511. Tornado Brass Elbow Fitting 1/4 in. MPT x 3/8 in. HB – 1522312. Tornado Vacuum Motor 115V Bypass 2-Stage – 1480013. Screw Phillips Truss Head #10-24 x 1/2 in. Stainless – 1784813. Screw Phillips Truss Head #10-24 x 1/2 in. Stainless – 1784813. Screw Phillips Truss Head #10-24 x 1/2 in. Stainless – 1784814. Tornado Washer Plain #10 I.D. Stainless – 1785014. Tornado Washer Plain #10 I.D. Stainless – 1785015. Tornado Washer Plain .328″ I.D. Stainless – 1919116. Screw #8-32 x 1/2 in – 1925517. Tornado Spotter Solution Tank – 1949018. Tornado Spotter Recovery Tank – 1949119. Over-Center Latch with Keeper – X905920. Tornado Wheel 6 in. x 1-1/4 in. – 1950521. Tornado Wheel Spacer 5/16 in. ID x 1/2 in. OD – 1950622. Tornado Nylon Insert Lock Nut 5/16 in. Stainless – X8248SS23. Tornado Vacuum Stack and Float Cage Assembly – 1951624. Tornado Intake Screen – 1951725. Extractor Foam Filter 1-3/4 in. OD x 1/2 in. – X271526. Tornado Brass Pipe Nipple 1/4 in. MPT x 4 in. – 1952227. Tornado Brass Adapter Fitting 1/4 in. FPT x 1/4 in. HB – 1952328. Tornado Nylon Elbow Fitting 1/8 in. MPT x 1/4 in. HB – 1952429. Tornado Solution Filter Screen – 1952530. Tornado Solution Hose 1-1/4 in. to Filter Screen – 1952831. Tornado Lock Washer – 1953032. Tornado Wheel Screw 5/16-18 x 3 in. Stainless – 1953233. Tornado Warning Label – 1953334. Screw #10-16 x 1/2" – 1956535. Tornado Solution Tank Gasket – 1961036. Tornado Switch Label Vacuum/Off/Spray – 1961137. Plain Washer .563 ID – 1961637. Plain Washer .563 ID – 1961638. Tornado Vacuum Motor Shroud – 1993739. Tornado External Tooth Lock Washer #10 Stainless – 3001939. Tornado External Tooth Lock Washer #10 Stainless – 3001940. Tornado Vacuum Motor Bottom Gasket – 3045640. Tornado Vacuum Motor Bottom Gasket – 3045641. Tornado Vacuum Motor Top Gasket – 3045742. Tornado Rocker Switch 15A DPDT – 3047243. Tornado Vacuum Motor Mounting Bracket – 3047544. Screw Phillips Truss Head #10-24 x 1/2 in. Stainless – 1784844. Screw Phillips Truss Head #10-24 x 1/2 in. Stainless – 1784844. Screw Phillips Truss Head #10-24 x 1/2 in. Stainless – 1784845. Tornado Logo Label 1-3/4 in. x 7-1/4 in. Black – 3081446. Tornado Power Cord Assembly – 1949947. Tornado RFI Filter – 3106748. Tornado Pump Plate – 3147149. Solution Pump without Mounts or Fittings – FJ508250. Tornado Pump Mounting Bracket – 31490Find genuine Tornado 98220 main assembly replacement parts for the PS Series professional spotter, Model 98220. The main assembly is the machine seen whole: the solution tank 19490 and recovery tank 19491 with the latches X9059 that clamp them, the two-stage bypass vacuum motor 14800 under its shroud 19937, the vacuum stack and float cage assembly 19516 that shuts the machine off when the recovery tank fills, the intake screen 19517 that protects it, the solution pump FJ5082 on its plate 31471, the rocker switch 30472, the RFI filter 31067 and the power cord assembly 19499 behind the electrical cover, the six-inch wheels 19505 on their spacers 19506, and the brass and nylon fittings, hoses, screws and washers that hold it all together.
This sheet is the Series G build of the PS Spotter. If the plate on your machine shows a different series, call us at 763-535-0770 before ordering — a few positions changed between series, and we will confirm the right part against your serial number.
The list below follows the callout numbers printed on the schematic, 1 to 51. Two things in it are the factory’s own and worth knowing. Screw 17848 is called out twice, at 13 and at 44, with eleven at one position and ten at the other — it is one part number appearing in two places, so both rows point at the same listing. And solution hose 19527 is in Tornado’s parts table as item 51 but has no numbered bubble anywhere on the diagram; we list it because the parts table does, but there is nothing on the drawing to point at, which is why its row is marked and why it will carry no dot.
Tornado 98220 Main Assembly Parts List
Tornado 98220 Main Assembly Parts – Frequently Asked Questions
Why is screw 17848 listed twice on the Tornado 98220 main assembly?
Because the factory calls it out at two separate positions on the drawing — eleven pieces at one and ten at the other, twenty-one in total. It is a single part number appearing twice, not two different screws, so both rows link to the same listing.
I cannot find item 51 on the diagram. Where is the solution hose?
Nowhere, and that is not your mistake. Tornado’s parts table lists solution hose 19527 as item 51 with a quantity of two, but the drawing carries no bubble 51 — the table and the diagram disagree. The part is genuine and the factory cross-reference confirms it across the spotter family.
My Tornado 98220 sounds normal but will not pick up water. What should I check?
Start with the float shut-off. If the float ball in cage assembly 19516 is stuck up on its seat the machine reads as having lost all suction with an empty tank. Then check the intake screen 19517 for blockage, the tank latches X9059 for a joint that is no longer clamped tight, and the motor gaskets 30456 and 30457 — a vacuum system leaks air far more readily than it leaks water.
Which parts on this sheet are Series G only?
The pump plate 31471 and the pump mounting bracket 31490 are Series G parts, as are the electrical components cover and its gasket on the solution tank sheet. Earlier series used different hardware in those positions. Read the series and the serial number off the plate on the solution tank, and call 763-535-0770 if you are not sure which applies to your machine.
How do I order Tornado 98220 main assembly parts or get help identifying one?
Click any part in the list above to add it to your cart, or call us at 763-535-0770. Our staff at 5415 West Broadway, Crystal, MN 55428 has been servicing Tornado equipment since 1956 and can confirm the right part from your model and serial number. Parts shown as call for price are factory-order items we will quote when you call.
Looking for a different assembly? Browse every section for this machine on the Tornado PS Spotter 98220 machine page, or call us at 763-535-0770 and we will identify the part for you. All eight assemblies for this machine are indexed on the Tornado 98220 PS Spotter parts hub.
